A Simple Guide to WiFi Networking

What is WiFi Networking?

In this day and age, the most common way of accessing the internet is wirelessly. Now, you can connect to a WiFi network at your local coffee shop, shopping center, office building, and at home.

WiFi networking gives you the ability to wirelessly connect multiple devices to your personal wireless network or any WiFi hotspot.

The concept of wireless networking can be difficult to understand. There are numerous technical terms and abbreviations involved. Here we will discuss the different components that make WiFi networking possible.

We offer complete cell phone signal booster kits for rural areas:
Attention business & property owners, installers and integrators

Take advantage of our system design and installation services. Learn more or call us for a free consultation: 1-800-969-8189.

What is the Internet?

The first element in WiFi networking is the internet. After all, the end goal is to wirelessly connect to it. So, what IS the internet?

The internet is commonly illustrated as a globe or a cloud, but it's neither of those things. The intent is a global network that is made up of millions of computers that communicate with each other. All of the devices connected to the internet, such as routers, servers, cell phone towers, radios, satellites, and other devices, create the network of networks. A more realistic representation of the internet is a whole bunch of cables connecting a whole bunch of computers all over the world.

One of the most important computers connected to the internet is the servers – huge data storage units that contain the information we desire. Anytime we request information from the internet, it’s forwarded to the servers for an answer. These huge computers live in data centers all over the world.

What Does a Broadband Modem Do?

Many people think modems and routers are the same thing, BUT modems and routers are different devices; they use different technologies to perform different jobs.

Modems are used to establish a connection between the internet and a computer or router in your home or office; the connection is facilitated by an internet service provider (ISP).

There are three types of modems: cable, DSL (Digital Subscriber Line), and Dial-Up. Depending on the type of modem you have will determine how it connects to the internet, either through cable lines or phone lines. The devices that communicate with the internet don’t speak the same language as the cable or phone lines. The modem (abbreviation for modulator-demodulator) acts as a translator; it modulates (codes) and demodulates (decodes) all of the information that is being transmitted through the internet.

Generally, the back of most modems contains three important ports:

  • A LAN or Ethernet Port: Used to connect to a router or an ethernet compatible device, such as a desktop, laptop, or game console.
  • A Service-Related Port: Consists of a telephone port (Dial-Up and DSL modems) or a coaxial port (cable modems) that connects to the service line.
  • A Power Port: Used to feed power to the modem.

Only one device can be directly connected to the modem for internet access. To connect all of your smart home devices, you might need a router. Some ISPs provide their customers with modem router combos; one device achieves the same result as two standalone products.

What Does a Router Do?

Routers allow devices in your local area network (LAN) – a network of computer networks within a small area, such as a home, small office, school, and business – to communicate with each other and the internet. They manage all of the incoming and outgoing information and direct it to the correct location within your own private network.

To allow multiple devices to connect to the internet, an ethernet cable is used to connect the router to the modem. One end of the cable plugs into the WAN or Internet port on the router, and the other end plugs into the Ethernet or LAN port on the modem.

Routers can create wired or wireless networks.

Wired Network Connection

Wired networks are most common in places with a large number of computers, like business buildings. That doesn’t mean that only businesses can have a wired network, some people prefer to wire all or some devices in their homes. Wiring your devices is called ethernet backhaul, which is a fancy way of saying that the backbone of your home networking system is made up of a wired connection rather than a wireless one.

On the back of a router, in addition to the WAN or Internet port, you will find four LAN ports. Those ports are used to connect your wired devices for internet access. If four LAN ports are not enough, a hub or switch - boxes composed of numerous LAN ports - can be used to expand the number of LAN ports.

To conduct an ethernet backhaul, ethernet cables are required. There are different types of ethernet cables; each can transfer information at different speeds:

  • Fast Ethernet → Cat-5 Cables → Can transfer information at 100 Mbps
  • Gigabit Ethernet → Cat-5e and Cat-6 Cables → Can transfer information at 1Gbps
  • 10 Gigabit Ethernet → Cat-6a and Cat-7 → Can transfer information at 10 Gbps

The ethernet cables don’t really affect your internet connection speed because the speeds provided by your ISP are the bottleneck. However, if you tend to transfer a lot of data between the devices in your LAN, then having faster cables would be beneficial.

Wireless Network Connection

Wireless networking is the most common and convenient way of accessing the internet. A wireless network is made up of a wireless access point (AP) and WiFi clients. An AP is a networking device that broadcasts a wireless signal, commonly referred to as WiFi (Wireless Fidelity), to allow WiFi clients to connect to it. Most wireless routers have APs built-in to them. WiFi clients are the wireless devices that can pick up on the WiFi signal and connect to it, such as smartphones, laptops, tablets, game consoles, smart TVs, and more.

Rather than drilling holes and using cables, built-in antennas allow the WiFi clients to communicate with the wireless router over the air, creating a wireless local area network (WLAN or wireless LAN). The antennas broadcast radio waves that allow the clients to connect to the internet. The radio waves transmit information using two frequency bands – 2.4 GHz and 5GHz. The main differences between the two bands are range, speed, and bandwidth. The 2.4 GHz band allows the radio waves to travel further but at a slower speed. On the other hand, the 5 GHz frequency travels at a faster rate, but it has a shorter range. Some routers only use one frequency bands (single-band) to transmit data, and others have the capability to use both (dual-band). In addition, newer router models are tri-band, meaning that they can host one 2.4 GHz signal and two separate 5 GHz signals.

All WiFi compatible clients (most of the newer mobile devices are WiFi compatible) have wireless network adapters and antennas built into their hardware to pick up on the radio waves. Older devices that don't have the WiFi compatibility feature, can be modified to be WiFi compatible with the help of a USB or PCle WiFi adapter. To pick up on the radio waves, a wireless connection must be established between the clients and the router.

Routers have their own network name (Service Set Identifier or SSID) and password; this helps protect your virtual private network (VPN). Through the setting of the WiFi clients, you can wirelessly connect to the network for WiFi access.

All WiFi devices (WiFi routers, mobile phones, tablets, and computers) have to follow a set of protocols that determine the WiFi functionalities.

IEEE 802.11 WiFi Standards

All devices that have anything to do with WiFi have to follow the IEEE 802.11 networking standards. The IEEE standards have been certified by the WiFi Alliance – a nonprofit organization created to certify IEEE 802.11 products and to promote them as wireless LAN standards.

The purpose of the wireless communication standards is to improve on the users' wireless networking experience. New standards are developed to fill in any gaps and to account for new wireless technology.

Each standard establishes the maximum WiFi speed, range, frequency band, and additional characteristics to improve on the previous standard.

WiFi Standards Year Issued Theoretical Max Speed Theoretical Range Indoors Frequency
802.11b (WiFi 1) 1999 11 Mbps ≈ 115 ft 2.4GHz
802.11a (WiFi 2) 1999 54 Mbps ≈ 115 ft 5GHz
802.11g (WiFi 3) 2003 54 Mbps ≈ 125 ft 2.4GHz
802.11n (WiFi 4) 2009 600 Mbps ≈ 230 ft 2.4GHz and 5GHz
802.11ac (WiFi 5) 2014 1.3 Gbps ≈ 150 ft 5GHz (2.4GHz with 802.11n technology)
802.11ax (WiFi 6) 2019 9.6 Gbps   TBD 2.4GHz and 5GHz

The latest standards are backward compatible with the earlier versions. However, the devices will only be as fast as the standard they operate under. For example, if your smartphone operates under the 802.11n standard, and your home router operates under the 802.11ax standard, the smartphone will only tap into the capabilities offered by the 802.11n standard. The same thing happens if the smartphone operates under 802.11ax and the router operates under 802.11n. Basically, in order to reap the benefits of the newest WiFi standard, all of your devices will have to operate under the same one.

It's important to note that these standards are built into the devices' hardware in the form of chips. The WiFi standards cannot be upgraded through a simple firmware or operating system update, you will have to purchase devices with the technology built-in.

WiFi Security Protocols: Protect your Network

Due to WiFi clients and router communicating over the air, any device can connect to your wireless network, which creates a serious security threat.

Similar to how WiFi standards are upgraded to fill in gaps, the security algorithms are upgraded to make them more secure for the user.

There are different wireless security protocols available:

  • WEP- Short for Wired Equivalent Privacy, this method was developed in 1999. It only protects wireless networks from the average user which makes your network vulnerable to hackers.
  • WPA- Short for WiFi Protected Access, this method improved on WEP, making it a little bit better. However, it didn't take long for hackers to bypass the updated security features.
  • WPA2- This method was based on the Advanced Encryption Standard technology (AES). AES is approved by the United States government for encrypting the information classified as top secret. If it protects the government, it must be good to protect your wireless home networks. It provides stronger data protection and user authentication control.
  • WPA3- The current form of network security introduced in 2019. It provides more protection for the WiFi clients connected to private and public networks. In addition, it makes it harder for hackers to access your network. WPA3 is the security protocol we recommend.

How to Extend the WiFi Range?

The WiFi range offered by the WiFi standards are theoretical; they are based on perfect conditions. In the real world, the range can be affected by building material, walls, and furniture. Therefore, oftentimes, the range of the router is not enough to cover your whole home. As a result, you could experience slow speeds and connectivity issues.

Gadgets like range extenders, mesh networks, and long-range antennas can help extend the range of your WiFi connection. Both have the option of being wired or wireless.

Range extenders wirelessly connect to your router to access the internet. Once the connection has been established, it's recommended to place the extender close enough to the router for a reliable signal, but far enough away to where it can still reach the problem areas. The extender repeats the signal it’s receiving from the router. To do so, it creates its own network; it’s almost like having two routers in your home. The extender will have its own network name and password. When you’re walking around your home you will manually have to switch to the networks you are closest to.

Mesh network systems are one of the most popular ways to extend your network. They are designed to blanket your entire home with a reliable, high-speed, WiFi connection. Mesh kits consist of 2 or 3 nodes. The nodes work together to create a whole-home WiFi solution. One of the mesh nodes is directly connected to the modem for internet access. That node basically takes over the router's job. The other nodes can be placed anywhere in your house to patch up the problem areas. Similar to the extender, it recommended to place the nodes close enough to one of the nodes for a reliable signal, but far enough away that it can reach the problem areas. The main node wirelessly shares its internet connection with the nodes that are within its range. Those nodes, then, wirelessly share their internet connection with the nodes that are within their range. This way even the furthest node can have an internet connection. Mesh networks create one seamless WiFi network. As you roam around your house, your devices will automatically connect to the node that is closest to it.

The range extenders don't need to be purchased from the same manufacture (Netgear, Linksys, Tp-Link, etc.) as your router or modem.

WiFi Networking in Action

How exactly does information wirelessly travel to and from the internet?

Let's say you're researching the new iPhone on your laptop. After you type in your query on google and press enter, the WiFi adapter in the laptop modulates the data into radio waves and transmits it through its antennas. The wireless router grabs the radio waves and directs the information to the modem. The modem modulates the cable or phone line language to direct the query through the intent. The query will travel through numerous computers to reach the server that contains the search results. Once the results have been gathered, the data will make its way back through the cables until it reaches the modem. The modem will demodulate the information and direct it to the router. This time, the router will modulate the data into radio waves and transmit it through its antennas. The laptops antenna will pick up on the radio waves and the WiFi adapter will demodulate the data. Lastly, the search results will pop up on your screen.
