The Arrow 5G - LPDA Cellular Antenna - Bolton Technical

SKU: BT151250

Free Standard Shipping FREE Standard Shipping*
The Arrow 5G - LPDA Cellular Antenna
$249.99
$219.99
$30.00 off
  • 5G Ready
  • Over 5 Miles of Range
  • Up to +12 dBi Gain
  • Wideband, Covers 617 – 3800 MHz
  • Weatherproof Construction
Recommended Add Ons
Pay With Affirm
Payment Logos
Phone
Need help finding the right booster? Speak to a Signal Expert
1-800-470-6777
Report Incorrect Product Information
Support Guarantee
USA based
customer support.
Shipping Guarantee
FREE shipping
on all orders.
Refund Guarantee
30 day money-back
guarantee.
Warranty Guarantee
2 year manufacturer's warranty included.
Bolton Technical Reseller
The Arrow 5G - LPDA Cellular Antenna - Bolton Technical
$219.99

Read Featured Reviews From Actual Customers Read All Reviews

No Signal Left Behind

The Arrow brings stronger 4G and 5G signals operating on the 617 – 3800 MHz bands from any North American carrier. Supported service providers including Verizon, AT&T, T-Mobile, and more.

What Bad Reception?

Featuring over 5 miles of range, the Arrow delivers the best signal possible directly to your home or business. Cell tower distance is no problem for this LPDA.

Not Your Standard
Directional Antenna

Offers peak gain of +12 dBi with balanced gain across all frequencies. More powerful than traditional Yagi antennas and other LPDA antennas on the market.

For any Roof Anywhere

Designed for rural homes and businesses, but works in any signal environment. Weatherproof, Arrow 5G delivers superior performance to your cell phone signal booster, cellular modem, router, or hotspots.

Bolton Technical Arrow 5G Details

The Arrow 5G is a wideband, high-performing, 50 Ohm log-periodic antenna. With over 5 miles of range and up to 12 dBi gain, it brings superior signal from any cellular carrier into your home or business building. Offers more power and reach than other LPDA and Yagi antennas on the market. It’s the perfect antenna for weak signal areas, but can be used with a signal booster, cellular router, or hotspot in any signal environment. 5G ready, it’ll work for the next decade and beyond.

  • 5G Ready
  • High Gain – Up to 12 dBi
  • Wideband – 617 to 3800 MHz
  • Weatherproof
  • 50 Ohm System with N-Female Connector
  • Easy Installation
Who is it for?
  • People in rural areas desperately searching for 4G/5G signals.
  • Businesses needing the absolute best 4G/5G outdoor antenna.
What's in the box?
  • 1x The Arrow 5G LPDA Antenna with Mount
  • 2x U-Bolts
Technical Specifications
The Arrow 5G Antenna
Frequency Range 617-960 MHz
1710-2700 MHz
3300-3800 MHz
Gain 10 dBi
11 dBi
12 dBi
Polarization Vertical
Beam Width Horizontal 56 deg
Vertical 49 deg
VSWR ≤2.5 / ≤2.0 / ≤2.0
Front-To-Back Ratio 20 dB
Input Power, Maximum 25w
Impedance 50 Ohm
Lightning Protection DC Ground
Connector Type N Female or 4.3-10 Female
Size H x W x D 1380 x 240 x 92 mm
54 x 9.4 x 3.6 in
Weight, without Mounting Kit 1.8 kg
2.0 lb
Mounting Hardware 38 ~ 60 mm
1.5 ~ 2.3 in
Reflector Finish Aluminum
Radome Material Aluminum

Frequently Asked Questions

What 5G Bands does the Arrow 5G Cover?

The Arrow 5G covers all T-Mobile's low-band 5G, Verizon’s n2, n5, and n66 low-band 5G, Verizon’s n77 mid-band 5G, and AT&T’s n5 low-band 5G plus n77 mid-band 5G.

When Should I Buy the Arrow 5G?

The Arrow 5G is a more powerful cellular antenna than a typical yagi, but less powerful than the Bolton Long Ranger. It is best used in areas with weak cellular signal or difficult terrain, where its directionality can be its best asset.

Importantly, you should be sure your system can handle the increased gain of The Arrow 5G. For example, if you live in a strong signal area and don’t have a system with automatic gain control, there is a risk of signal overload using high-gain antennas.

It is a strict upgrade over the traditional 4G Bolton Arrow, as it covers the same bandwidths in addition to 5G.

What Kinds of Signal Does the Arrow 5G Capture? What Radio Bandwidths?

The Arrow 5G captures any signal between the 617-3800 MHz bandwidths. That includes low-band 5G and all 4G & LTE cellular signals. This covers all US carriers (AT&T, T-Mobile, Verizon, U.S. Cellular and more), Canadian carriers (Rogers, Bell, Telus, more), Mexican carriers (Telcel, Movistar, AT&T Mexico), and far more.

What Does dB Mean? What About Gain?

dB refers to the power gain of the antenna, and the higher the number, the more powerful the signal from that antenna. As dB is measured on a logarithmic scale, every +3 dB represents a doubling of the power.

Will the Arrow 5G Work with My Carrier?

The Arrow will work on any US or Canadian carrier, as well as most cellular carriers worldwide. If you are not sure your country’s carrier will work with The Arrow, verify whether your service falls within the 617-3800 MHz bandwidth, and if so, it will work.
